1. Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
2. The wood products: voice box, game cabinets, computer tables, sewing machines table,instruments.
3. Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
4. Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.
1. The CNC router machine’s body is strong, high-precision, reliable and durable.
2.Imported high-precision ball screw which moving smoothly to ensure the machine’s high precision.
3. High-performance drive motor to ensure the machine’s high speed and accuracy.
4. Perfect design and top quality accessories to minimize the CNC router machine’s failure rate.
5. Breakpoint specific memory to keep the carving status when power off, processing time forecast and other functions in case of the accidental power outages.
6. 2 motors for Y-axis with high speed.
7. Artcam and JDpaint software can be compatible with DWG, PLT, DXF and NC(G code) file.
Technical parameters:
Description | Parameter |
X,Y,Z Working Area | 1300x2500x200mm |
X,Y,Z Reposition Accuracy | ±0.03mm |
Table Surface | T-slot Table |
Frame | Welded Structure |
Driving system | Helical Rack and Pinion Drive |
Guide way | Taiwan Hiwin square rails |
Max. Rapid Travel Rate | 33000mm/min |
Max. Working Speed | 25000mm/min |
Spindle Power | 4.5kw air-cooling spindle |
Spindle Speed | 0-18000rpm |
Drive Motors | Stepper System |
Working Voltage | 220V,single phase or 380V,3 phase |
Command Language | G Code |
Operating System | RichAuto DSP control system |
Computer Interface | USB |
Flash Memory | 128M(U Disk) |
Collet | ER20 |
Software Compatibility | Artcam Software and JDpaint software or other CAD software |
N/G weight | 1000/1100kg |
Package dimension | 3300*2150*1800mm
|
Samples:
Warranty: one year warranty, any parts damaged in warranty, we will replace for free.
After sale service:
1. We offer life-long technical support by call, email.
2. Our technician can give you remote guide online if you have any question.
3. We can record videos of the machine operating.
4. Free training course in our factory.
5. Engineer available to service machinery overseas.
6. Machine will be adjusted before it is delivered, operation USB/CD will be included.
Package:
